- Size: 10*7*2.5
- Place of Origin: China
- Brand Name: Vinot
- Model Number: DYF-1200
- Weight: 5500.000 kg
Machine Details:
- Size: 10*7*2.5
- Place of Origin: China
- Brand Name: Vinot
- Model Number: DYF-1200
- Weight: 5500.000 kg
Main Technical Parameter
Model | DYF-1000 |
Main and auxiliary extruder screw diameter | 55mm/ 50mm |
L/D ratio | 28:1 |
Main and auxiliary extruder electrical power | 11kw/ 5kw |
Width of production | 1000mm |
Main bubble specification(arbitrary eligibility) | 10×3.4mm/25×10mm/3.2×6mm/30×10mm |
Output | 40-80kg/h |
Total installed capacity | 75kw |
Overall dimension | 10000×7000×2500mm |
Gross weight | 5T |
Model | DYF-1200 |
Main and auxiliary extruder screw diameter | 65mm/ 55mm |
L/D ratio | 28:1 |
Main and auxiliary extruder electrical power | 15kw/ 11kw |
Width of production | 1200mm |
Main bubble specification(arbitrary eligibility) | 10×3.4mm/25×10mm/6×3.2mm/30×10mm |
Output | 60-90kg/h |
Total installed capacity | 85kw |
Overall dimension | 10000×7500×2500mm |
Gross weight | 5.5T |
Model | DYF-1500 |
Main and auxiliary extruder screw diameter | 75mm/ 65mm |
L/D ratio | 28:1 |
Main and auxiliary extruder electrical power | 18.5kw/ 15kw |
Width of production | 1500mm |
Main bubble specification(arbitrary eligibility) | 10×3.4mm/25×10mm/6×3.2mm/30×10mm |
Output | 60-100kg/h |
Total installed capacity | 98kw |
Overall dimension | 10000×8000×2500mm |
Gross weight | 6.8T |
