- Size: 4.2*2.2*2.4
- Place of Origin: China
- Brand Name: Vinot
- Model Number: YT-41200
- Weight: 4200.000 kg
Machine Details:
- Size: 4.2*2.2*2.4
- Place of Origin: China
- Brand Name: Vinot
- Model Number: YT-41200
- Weight: 4200.000 kg
Main Technical Parameters
Model | YT-4600 | YT-4800 | YT-41000 | YT-41200 | |||||
Suitable Material | LDPE HDPE | ||||||||
Screw Diameter | Φ50 | Φ55 | Φ65 | Φ70 | |||||
L/D | 28:1 | 28:1 | 28:1 | 28:1 | |||||
Printing Color | 2 | 2 | 2 | 2 | |||||
Horinzal | 0.2mm | 0.2mm | 0.2mm | 0.2mm | |||||
Vertical | 0.2mm | 0.2mm | 0.2mm | 0.2mm | |||||
Printing Extrance Width(mm) | 600 | 800 | 1000 |
1200
| |||||
Max. Printing Width(mm) | 580 | 760 | 980 | 1160 | |||||
Length of Printing Product(mm) | 191-1000 | 191-914 | 191-914 | 191-1200 | |||||
Diameter of Roll Material(mm) | φ450 | φ450 | φ450 | φ450 | |||||
Printing Speed (m/min) | 5-50 | 5-50 | 5-50 | 5-50 | |||||
Thickness of Printing Plate(mm) | 2.3 | 2.3 | 2.3 | 2.3 | |||||
Total Power(kw) | 12.2 | 16.2k | 19.25 | 23.55 | |||||
Overall Dimension(m) | 4.2*1.6*2.4 | 4.2*1.8*2.4 | 4.2*2.0*2.4 | 4.2*2.0*2.4 | |||||
Weight(kg) | 3000kg | 3500kg | 4000kg | 4200kg | |||||
